HVAC Chair Rail
Inventor: Sanjeev Jain
The Chair Rail System is mounted along interior walls to provide conditioned air and electrical outlets throughout a room. This provides a clean, modern look to a room as outlets and air diffusers are removed from view and carried within the Chair Rail System.
Each linear foot of Chair Rail will provide (TBD) CFM of conditioned air. Total linear footage of Chair Rail will be provided for a room's air conditioning needs.
The Chair Rails will be connected to HVAC ducting within the walls of a room. These connections will be sized and numbered to provide sufficient CFM of conditioned air to heat and cool the room.
Each linear foot of Chair Rail will provide (TBD) CFM of conditioned air. Total linear footage of Chair Rail will be provided for a room's air conditioning needs.
The Chair Rails will be connected to HVAC ducting within the walls of a room. These connections will be sized and numbered to provide sufficient CFM of conditioned air to heat and cool the room.
A wall mounted rail system for providing aesthetic appeal to
any room while allowing for continuous air flow
and easily-accessible electrical outlets.
any room while allowing for continuous air flow
and easily-accessible electrical outlets.
INTEGRATED HVAC AIR DUCTS
Integrated air ducts allow for warm and cool air to escape from the rail unimpeded while providing proper heating and cooling to any room.
INTEGRATED ELECTRICAL AND DATA OUTLETS
Electrical wiring is provided throughout the rail system to ensure adequate power supply and availability wherever chair rail is placed.
COMPONENTS AND ASSEMBLY
The general construction of the rail system is durable and easy to assemble.
